SMSL DO200 MQA VOLLSTÄNDIGE DECODIERUNG

USB-/OPT-/Koaxial-/AES-Eingänge unterstützen die MQA-Decodierungsfunktion und unterstützen MQA-CD. Alle Eingangsanschlüsse unterstützen DSD (außer BT), Koaxial-, Opt- und AES-Unterstützung Dop64.

HOCHWERTIGER CHIPSATZ

2 x fortschrittliche ES9068AS D/A-Chips, THD + N so niedrig wie 122 dB. 5 x High-End-Dual-Operationsverstärker OPA1612A und eine große Anzahl an Audiokomponenten. XMOS XU-216, eine echte 32-Bit-USB-Lösung, unterstützt Dop256 und natives DSD512, PCM unterstützt bis zu 768 KHZ.

BLUETOOTH5.0 DAC

Der neueste Bluetooth-Chip von Qualcomm unterstützt LDAC 24 Bit/96 kHz, APTX/HD, SBC und AAC. Die drahtlose Bluetooth-Verbindung ist bequemer. SMSL DO200 kann einen CD-Player, der MQA nicht unterstützt, in einen MQA-CD-Player verwandeln. Dabei wird nicht nur MQA-Rendering unterstützt, sondern SPDIF unterstützt auch die vollständige MQA-Erweiterung.

GERÄUSCHARMES NETZTEIL

Lineare Netzteile mit diskreten Komponenten und mehrere rauscharme Netzteile, die speziell für analoge Schaltkreise entwickelt wurden und gleichzeitig die Energieeffizienz verbessern und den Stromverbrauch senken.

VOLLFUNKTIONS-FERNBEDIENUNG

Vollbild-Farb-IPS-Display mit Dimmerfunktion. Ausgestattet mit vollfunktionaler Fernbedienung. Hochwertige vergoldete Eingangs- und Ausgangsanschlussklemmen. Mit HI-RES-Zertifizierung.

Technical Details

Product mode
SMSL DO200
THD+N
0.00008%(-122d8)
Dynamic range
XLR 129dB; RCA 125dB
SNR
128dB
Output impedance
100Ω
Input
USB / Optical / Coaxial /Bluetooth / 12S / AES / EBU
Output
RCA / XLR
USB transmission
Asynchronization
USB
1bit, 16-32bit
Optical / Coaxial / AES / EBU
1bit, 16-24bit
USB/ I2S
PCM 44.1-768kHz; DSD 2.8224~22.5792MHz
Optical / Coaxial / AES / EBU
PCM 44.1-768kHz; DSD64(DoP)
Bluetooth specification
BT 5.0 ( support SBC / AAC / APTX / APTX HD / LDAC )
Power Consumption
5W
Standby power
<0.5W
Size
210 X 40 X 170mm ( WxHxD )
Machine weight ( including remote control )
1.2KG
Packing weight
1.9KG
Package list
1* SMSL DO200
1* Remote control
1* Bluetooth antenna
1* USB cable
1* AC power cable
1* User manual
1* Warranty card
Inside the Box
  • 1 x SMSL DO200
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL DO200 Comes with a 1 year warranty on the DAC only. Warranty doesn't apply to the included accessories.
