External Clock Input & ROHM BD34352EKV DAC Chip

The D200 features the ROHM BD34352EKV DAC, delivering exceptional clarity, precision, and detail. Paired with an external clock input, it ensures ultra-low jitter for audiophile-grade digital-to-analog conversion. This combination achieves accurate timing and natural sound reproduction across all genres.

All-New CK-03 Clock Circuit

Equipped with SMSL’s self-developed CK-03 clock processing circuitry, the D200 significantly reduces clock jitter. Supporting 10MHz standard or atomic external clock inputs, it achieves professional-level stability and precision for digital playback.

High-Resolution Audio Support

With the third-generation XMOS XU316, the D200 supports PCM up to 32bit/768kHz and DSD512. It also fully decodes MQA and MQA-CD via USB, optical, and coaxial inputs—ensuring studio-master quality from multiple digital sources.

Fully Balanced Preamp with Ultra-Low Distortion

The D200 integrates two NJU72315 chips to form a true balanced preamplifier stage, delivering distortion as low as 0.00013%. This architecture ensures clean, transparent output, making it ideal for high-fidelity audio systems.

Qualcomm Bluetooth with Hi-Res Wireless Support

Powered by Qualcomm’s next-generation Bluetooth chipset, the D200 supports LDAC, aptX HD, and AAC. Combined with an external antenna, it offers stable wireless transmission and Hi-Res playback with convenient remote control for play, pause, and track navigation.

Premium Display & Ergonomic Design

The 1.9-inch fully laminated tempered glass display offers higher light transmittance, better durability, and automatic wake-up functionality. With its minimalist chassis, the D200 blends seamlessly into any audiophile desktop setup.

Perfect Hi-Fi System Integration

When paired with SMSL’s PL200 CD transport and PA200 power amplifier, the D200 becomes the centerpiece of a complete high-fidelity system. Together, this “Hi-Fi Trinity” ensures precise signal reading, accurate decoding, and powerful amplification for a truly immersive listening experience.

Technical Details

Inputs
USB/Optical/Coaxial/Bluetooth
Outputs
RCA/XLR
Line Output Amplitude
XLR:5Vrms
RCA:2.5Vrms
THD÷N
0.00019%(-114dB)(UN-WTD)
Dynamic Range
XLR:123dB
RCA:121dB
SNR
XLR:123dB
RCA:121dB
USB Transfer Mode
USB 2.0 Asynchronous
USB Compatibility
Windows7/8/8.1/10/11 (Driver Required)
Mac OSX 10.6 above, Android, iOS, Linux(Driverless)
MQA Decoder
USB/Optical/Coaxial
Bluetooth
Support SBC, AAC, aptx, aptX HD, LDAC
Power Consumption
<10W
Standby Power Consumption
<0.5W
Dimensions
200x47.9x197.9mm(WxHxD)
Weight
1.214kg/2.68lbs
Inside the Box
  • 1 x SMSL D200
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL D200 Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.
